TMP35FS - Analog Devices

TMP35FS Details

• Manufacturer Part Number:

  TMP35FS

• Part Life Cycle Code:

  Obsolete

• Package Description:

  MS-012-AA, SOIC-8

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Accuracy-Max (Cel):

  4 Cel

• Body Breadth:

  3.9 mm

• Body Height:

  1.55 mm

• Body Length or Diameter:

  4.9 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e0

• Linearity (Cel):

  0.5 Cel

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Current-Max:

  0.05 mA

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Output Voltage-Max:

  2 V

• Output Voltage-Min:

  0.1 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.25

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Temperature Coefficient:

  POSITIVE ppm/°C

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Termination Type:

  SOLDER
