TMP89FH40NG - Toshiba

TMP89FH40NG Details

• Manufacturer Part Number:

  TMP89FH40NG

• Part Life Cycle Code:

  Active

• Part Package Code:

  DIP

• Package Description:

  0.600 INCH, 1.78 MM PITCH, LEAD FREE, PLASTIC, SDIP-42

• Pin Count:

  42

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Toshiba America Electronic Components

• Has ADC:

  YES

• Bit Size:

  8

• Clock Frequency-Max:

  10 MHz

• DAC Channels:

  NO

• DMA Channels:

  NO

• JESD-30 Code:

  R-PDIP-T42

• Length:

  38 mm

• Number of I/O Lines:

  36

• Number of Terminals:

  42

• PWM Channels:

  YES

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SDIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Speed:

  10 MHz

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.778 mm

• Terminal Position:

  DUAL

• Width:

  15.24 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER
