- Part Number TN2-L2-24V
- Manufacturer Panasonic
- Pin Count 10
- Part Category Relay or Contactor
- Package Category Other
- Footprint Name Other - TN2-L2-24V-3
- Released Date Jan 5, 2022
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
TN2-L2-24V Details
-
Manufacturer Part Number:
TN2-L2-24V
-
Pbfree Code:
Yes
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Obsolete
-
Package Description:
ROHS COMPLIANT
-
ECCN Code:
EAR99
-
HTS Code:
8536.49.00.50
-
Manufacturer:
Panasonic Electronic Components
-
YTEOL:
0
-
Body Breadth:
5.6 mm
-
Body Height:
9.8 mm
