TOP224P - Power Integrations

Description: AC/DC Converters 20W 85-265 VAC 30W100/115/230 VAC

Download TOP224P Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TOP224P - Power Integrations PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - PDIP-8 (P Package)_2021
click to zoom
3D Models
TOP224P - Power Integrations  - 3D model - Dual-In-Line Packages - PDIP-8 (P Package)_2021
click to zoom

TOP224P Details

  • Manufacturer Part Number:

    TOP224P

  • Pbfree Code:

    No

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    DIP

  • Package Description:

    0.300 INCH, PLASTIC, DIP-8

  • Pin Count:

    8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Power Integrations

  • YTEOL:

    0

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    VOLTAGE-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • JESD-30 Code:

    R-PDIP-T8

  • JESD-609 Code:

    e0

  • Length:

    9.59 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    1.65 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP8,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    4.45 mm

  • Surface Mount:

    NO

  • Switcher Configuration:

    BOOST

  • Switching Frequency-Max:

    110 kHz

  • Technology:

    CMOS

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    TIN LEAD

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

TOP224P Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the TOP224P is -40°C to 125°C, but it's recommended to operate within -20°C to 85°C for optimal performance and reliability.
  • To ensure proper biasing, make sure to provide a stable 5V to 15V supply voltage (VCC) and a minimum of 10uF decoupling capacitor between VCC and GND. Also, ensure the input voltage (VIN) is within the recommended range of 85V to 265V AC.
  • For optimal performance and EMI reduction, follow these layout guidelines: keep the input and output stages separate, use a solid ground plane, and place the decoupling capacitors close to the IC. Also, ensure the PCB is designed to handle the high-frequency switching of the TOP224P.
  • When selecting a transformer, consider the following factors: primary inductance, turns ratio, and core material. The transformer should be designed to handle the maximum output power and voltage of the TOP224P. Power Integrations provides a transformer selection guide to help with this process.
  • To ensure EMI compliance, use a common-mode choke and X-capacitors in the input stage, and a Y-capacitor in the output stage. Also, follow the layout guidelines mentioned earlier and use a shielded transformer. Power Integrations provides an EMI design guide to help with this process.
