Toshiba recommends a PCB layout with a thermal pad connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended, and the thermal pad should be connected to a ground plane or a heat sink.
To ensure reliable operation in high-temperature environments, it's essential to follow proper thermal design and layout guidelines. Additionally, consider using a heat sink or thermal interface material to reduce the junction temperature. Operating the device within the recommended temperature range and providing adequate cooling will help prevent thermal-related failures.
The TOTX1701A(F) has built-in ESD protection, but it's still essential to follow proper handling and storage precautions to prevent damage. Use an anti-static wrist strap, mat, or packaging materials, and avoid touching the device's pins or exposed internal components.
Yes, the TOTX1701A(F) is suitable for high-reliability and automotive applications. However, it's essential to follow the recommended operating conditions, and Toshiba recommends using the device in accordance with the AEC-Q100 standard for automotive applications.
Toshiba recommends a soldering profile with a peak temperature of 260°C (500°F) for a maximum of 10 seconds. The device should be soldered using a solder with a melting point above 217°C (423°F). Follow the recommended soldering conditions to prevent damage to the device.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TOTX1701A(F) Overview
Use the download button to access the TOTX1701A(F) schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like TOTX1,
or try a keyword search, such as Fiber Optic Transmitters
