TP43W013050 - Apem

TP43W013050 Details

• Manufacturer Part Number:

  TP43W013050

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.31

• Manufacturer:

  APEM Inc

• YTEOL:

  7

• Actuator Length:

  0.139 inch

• Actuator Type:

  STANDARD PLUNGER

• Body Breadth:

  8.1 mm

• Body Height:

  9.6 mm

• Body Length or Diameter:

  8.58 mm

• Bushing Diameter:

  0.225 inch

• Bushing Length:

  0.225 inch

• Bushing Type:

  UNTHREADED

• Contact (AC) Max Rating R Load:

  0.5A@48VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  0.5A@48VDC

• Contact Function:

  OFF-(ON)

• Contact Voltage(AC)-Max:

  48 V

• Contact Voltage(DC)-Max:

  48 V

• Electrical Life:

  20000 Cycle(s)

• Illumination:

  NON-ILLUMINATED

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• PCB Hole Count:

  8

• Packing Method:

  BULK

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  DPST

• Switch Type:

  MINIATURE SWITCH

• Terminal Finish:

  SILVER

• Termination Type:

  SOLDER
