TPA5511-DFPR - 3Peak Incorporated

TPA5511-DFPR Details

• Manufacturer Part Number:

  TPA5511-DFPR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  DFN-4

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  11 Weeks

• Manufacturer:

  3peak Incorporated

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  0.0011 µA

• Bias Current-Max (IIB) @25C:

  0.0011 µA

• Common-mode Reject Ratio-Min:

  90 dB

• Common-mode Reject Ratio-Nom:

  125 dB

• Frequency Compensation:

  YES

• Input Offset Voltage-Max:

  30 µV

• JESD-30 Code:

  R-PDSO-N4

• Length:

  1.4 mm

• Low-Bias:

  YES

• Low-Offset:

  NO

• Micropower:

  YES

• Number of Functions:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC4,.04,20

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR, 7 INCH

• Power:

  NO

• Programmable Power:

  NO

• Seated Height-Max:

  0.4 mm

• Slew Rate-Nom:

  0.003 V/us

• Supply Current-Max:

  0.0011 mA

• Supply Voltage Limit-Max:

  4 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Unity Gain BW-Nom:

  9

• Voltage Gain-Min:

  100000

• Wideband:

  NO

• Width:

  1 mm
