TPL2-01G-L2 - Nidec Copal

TPL2-01G-L2 Details

• Manufacturer Part Number:

  TPL2-01G-L2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.31

• Manufacturer:

  Nidec Copal Electronics Corporation

• YTEOL:

  8.1

• Body Breadth:

  7.5 mm

• Body Height:

  6.5 mm

• Body Length or Diameter:

  8.5 mm

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@30VDC

• Contact Voltage(DC)-Max:

  30 V

• Electrical Life:

  10000 Cycle(s)

• Illumination:

  RED LED

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Force-Max:

  3.43 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -10 °C

• Packing Method:

  BAG

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  DPDT

• Switch Type:

  MINIATURE SWITCH

• Terminal Finish:

  Gold (Au)

• Termination Type:

  SOLDER
