TPSD686K016R0070 - Kyocera AVX

TPSD686K016R0070 Details

• Manufacturer Part Number:

  TPSD686K016R0070

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Czechia, El Salvador

• ECCN Code:

  EAR99

• HTS Code:

  8532.21.00.50

• Factory Lead Time:

  13 Weeks

• Manufacturer:

  Kyocera AVX Components

• YTEOL:

  6.98

• Additional Feature:

  ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ

• Capacitance:

  68 µF

• Capacitor Type:

  TANTALUM CAPACITOR

• Dielectric Material:

  TANTALUM (DRY/SOLID)

• ESR:

  70 mΩ

• Height:

  2.9 mm

• JESD-609 Code:

  e3

• Leakage Current:

  0.0109 mA

• Length:

  7.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  10%

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, PLASTIC, 7 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  10%

• Rated (DC) Voltage (URdc):

  16 V

• Ripple Current:

  586 mA

• Size Code:

  2917

• Surface Mount:

  YES

• Tan Delta:

  0.06

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Shape:

  J BEND

• Width:

  4.3 mm
