Qorvo provides a recommended PCB layout and land pattern in their application note AN-2171, which can be found on their website. Following this layout ensures optimal performance and minimizes parasitic effects.
Qorvo offers a free online tool called Qorvo's RF Small Signal Model and S-Parameter Tool, which helps designers optimize the biasing and matching network for their specific application. The tool provides a starting point for design and can be used to simulate and optimize the performance of the TQM879026.
While the datasheet specifies an operating temperature range of -40°C to 85°C, Qorvo recommends derating the device's power handling and performance at temperatures above 70°C. It's essential to consult with Qorvo's application engineers or refer to their reliability reports for more information on high-temperature operation.
To prevent thermal runaway, it's crucial to ensure proper thermal management, such as using a heat sink or thermal pad, and to follow Qorvo's recommended assembly and soldering guidelines. Additionally, designers should implement over-temperature protection and current limiting in their design to prevent excessive power dissipation.
The TQM879026 is a sensitive device and requires proper ESD protection during handling and assembly. Qorvo recommends following standard ESD handling procedures, such as using an ESD wrist strap or mat, and storing the devices in anti-static packaging. It's also essential to ensure that the PCB design includes ESD protection components, such as TVS diodes or ESD arrays.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
TQM879026 Overview
Use the download button to access the TQM879026 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TQM87,
or try a keyword search, such as RF/Microwave Amplifiers
About Qorvo
Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
