TRN3-0523 - Traco Power

TRN3-0523 Details

• Manufacturer Part Number:

  TRN3-0523

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SIP-5

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  Traco Power

• YTEOL:

  5

• Additional Feature:

  ALSO -15V OUTPUT AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  80%

• Input Voltage-Max:

  13.2 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  9 V

• JESD-30 Code:

  R-PSMA-T5

• JESD-609 Code:

  e3

• Length:

  11.9 mm

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.1 A

• Output Voltage-Max:

  15.15 V

• Output Voltage-Min:

  14.85 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  11.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  6

• Total Power Output-Max:

  3 W

• Trim/Adjustable Output:

  NO

• Width:

  7.7 mm
