TRPS2-232-75+ - Mini-Circuits

Description: 2 Ways Core & Wire Power Splitter, 5 - 2300 MHz, 75Ω

Download TRPS2-232-75+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TRPS2-232-75+ - Mini-Circuits PCB footprint - Other - Other - AT3081
click to zoom
3D Models
TRPS2-232-75+ - Mini-Circuits  - 3D model - Other - AT3081
click to zoom

TRPS2-232-75+ Details

  • Manufacturer Part Number:

    TRPS2-232-75+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    7.3

  • Additional Feature:

    TR, 7 INCH: 500

  • Characteristic Impedance:

    75 Ω

  • Construction:

    MODULE

  • Input Power-Max (CW):

    26.99 dBm

  • Insertion Loss-Max:

    2.5 dB

  • Isolation-Min:

    15 dB

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    2300 MHz

  • Operating Frequency-Min:

    5 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    SPLITTER AND COMBINER

  • Surface Mount:

    YES

  • VSWR-Max:

    1.3
