• What is the recommended PCB layout and thermal management for optimal performance?
  A 4-layer PCB with a solid ground plane and thermal vias is recommended. Ensure a minimum of 1mm clearance around the device for heat dissipation. A thermal pad on the bottom of the device should be connected to a solid ground plane.
• How do I ensure electromagnetic compatibility (EMC) and reduce electromagnetic interference (EMI) in my design?
  Use a shielded enclosure, keep cables and wires away from the device, and use a common-mode choke or ferrite bead on the input lines. Ensure the PCB layout follows good EMC practices, such as separating analog and digital grounds.
• What are the recommended input and output capacitors for this device?
  Use X7R or X5R ceramic capacitors with a voltage rating of 10V or higher. For input capacitors, use 10uF to 22uF capacitors with an ESR of 10mΩ or less. For output capacitors, use 4.7uF to 10uF capacitors with an ESR of 10mΩ or less.
• How do I handle overvoltage protection and input voltage transients?
  Use a TVS (transient voltage suppressor) diode or a voltage clamp circuit to protect the device from input voltage transients. Ensure the TVS diode is rated for the maximum input voltage and has a response time of 1ns or less.
• What is the recommended startup and shutdown sequence for this device?
  Power up the device in the following sequence: VCC, then VIN, then enable the device. Power down in the reverse sequence. Ensure a minimum of 10ms delay between power-up and enable signals.
