TSC-124L3H,000 - TE Connectivity

TSC-124L3H,000 Details

• Manufacturer Part Number:

  TSC-124L3H,000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  12 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  7.5 mm

• Body Height:

  9.9 mm

• Body Length or Diameter:

  12.5 mm

• Coil Current(DC)-Max:

  0.006 A

• Coil Power:

  150 mW

• Coil Resistance:

  3840 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  AC/DC

• Contact (AC) Max Rating R Load:

  1A@120VAC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@30VDC

• Contact Voltage(AC)-Max:

  120 V

• Contact Voltage(DC)-Max:

  24 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1000 Vrms

• Dielectric Strength Between Open Contacts:

  400 Vrms

• End Contact Material:

  NICKEL TITANIUM ALLOY

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  6

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -30 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  12.5mm x 7.5mm x 9.9mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Sealing:

  EPOXY

• Surface Mount:

  NO

• Terminal Length:

  0.003500127000254001 inch

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  3 g
