The recommended land pattern for the TSL0808RA-101KR80-PF can be found in the TDK Corporation's application note or in the IPC-7351 standard. It is essential to follow the recommended land pattern to ensure reliable soldering and to prevent thermal and mechanical stress.
To prevent damage, handle the TSL0808RA-101KR80-PF by the edges, avoid touching the pads or components, and use an anti-static wrist strap or mat. Also, ensure the assembly area is clean and free from debris.
The maximum allowable voltage derating for the TSL0808RA-101KR80-PF is typically 80% of the rated voltage. However, it's recommended to consult with TDK Corporation's application engineers or refer to the device's datasheet for specific derating guidelines.
The TSL0808RA-101KR80-PF is rated for operation up to 125°C. However, it's essential to consider the device's power dissipation, thermal resistance, and derating factors when operating in high-temperature environments. Consult with TDK Corporation's application engineers or refer to the device's datasheet for specific guidance.
To ensure proper soldering, follow the recommended soldering profile, use a solder with a melting point below 260°C, and avoid excessive soldering temperatures or times. Also, inspect the solder joints for defects, such as cold solder joints or solder bridges.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TSL0808RA-101KR80-PF Overview
Use the download button to access the TSL0808RA-101KR80-PF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TSL08,
or try a keyword search, such as Fixed Inductors
