TSR0.5-2450SM - Traco Power

TSR0.5-2450SM Details

• Manufacturer Part Number:

  TSR0.5-2450SM

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD-10

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  Traco Power

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN, FCC

• Efficiency (Main Output):

  94%

• Input Voltage-Max:

  32 V

• Input Voltage-Min:

  6.5 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-PDMA-G10

• JESD-609 Code:

  e3

• Length:

  15.3 mm

• Line Regulation-Max:

  0.4%

• Load Regulation-Max:

  0.6%

• Moisture Sensitivity Level:

  2

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.5 A

• Output Voltage-Max:

  8 V

• Output Voltage-Min:

  3 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,10LEAD,.48

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER TEMPERATURE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.0106 Vrms

• Seated Height-Max:

  9.29 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  2.5 W

• Trim/Adjustable Output:

  YES

• Width:

  12.35 mm
