TSS-23HLN+ Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and footprint for the TSS-23HLN+?
  Mini-Circuits provides a recommended PCB layout and footprint in their application note AN-60-014, which can be found on their website. It's essential to follow this layout to ensure optimal performance and minimize parasitic effects.
• How do I achieve the specified return loss and insertion loss performance?
  To achieve the specified return loss and insertion loss performance, it's crucial to follow the recommended PCB layout, use a high-quality PCB material, and ensure proper soldering and assembly. Additionally, the device should be operated within the specified frequency range and power handling capabilities.
• What is the maximum operating temperature range for the TSS-23HLN+?
  The TSS-23HLN+ can operate from -40°C to +85°C, but the performance may degrade at higher temperatures. It's essential to consider the operating temperature range when designing the system to ensure reliable operation.
• Can I use the TSS-23HLN+ in a high-reliability or space-constrained application?
  Yes, the TSS-23HLN+ is designed for high-reliability applications and is suitable for use in space-constrained systems. However, it's essential to follow the recommended PCB layout, assembly, and testing procedures to ensure reliable operation.
• How do I handle ESD protection when handling the TSS-23HLN+?
  The TSS-23HLN+ is sensitive to electrostatic discharge (ESD). To prevent damage, it's essential to handle the device with ESD-protective equipment, such as wrist straps, mats, and bags, and follow proper ESD handling procedures.
