TSS-23LN+ - Mini-Circuits

Description: IC RF AMP CATV 30MHZ-2GHZ DQ1225

Download TSS-23LN+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TSS-23LN+ - Mini-Circuits PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - DQ1225_2021
click to zoom
3D Models
TSS-23LN+ - Mini-Circuits  - 3D model - Quad Flat No-Lead - DQ1225_2021
click to zoom

TSS-23LN+ Details

  • Manufacturer Part Number:

    TSS-23LN+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Date Of Intro:

    2019-02-18

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6.65

  • Additional Feature:

    LOW NOISE

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    17.6 dB

  • Input Power-Max (CW):

    13 dBm

  • Operating Frequency-Max:

    2000 MHz

  • Operating Frequency-Min:

    30 MHz

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    WIDE BAND LOW POWER
