TSSJ30 - KNITTER-SWITCH

TSSJ30 Details

• Manufacturer Part Number:

  TSSJ30

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  knitter-switch

• Actuator Length:

  0.224 inch

• Actuator Travel:

  1 mm

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  12.3952 mm

• Body Height:

  6.477 mm

• Body Length or Diameter:

  12.3952 mm

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.02 A

• Contact (DC) Max Rating R Load:

  0.02A@15VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  15 V

• Dielectric Withstand Volts:

  100VAC V

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  6.374 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Termination Type:

  SOLDER
