UF5408-E3/54 - Vishay

UF5408-E3/54 Details

• Manufacturer Part Number:

  UF5408-E3/54

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT, PLASTIC PACKAGE-2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6.07

• Additional Feature:

  FREE WHEELING DIODE

• Application:

  EFFICIENCY

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.7 V

• JEDEC-95 Code:

  DO-201AD

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  150 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  3 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  1000 V

• Reverse Recovery Time-Max:

  0.075 µs

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  30
