ULP12OAP1RSFCL1REDGRN - E-Switch

ULP12OAP1RSFCL1REDGRN Details

• Manufacturer Part Number:

  ULP12OAP1RSFCL1REDGRN

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  E-Switch Inc

• Actuator Length:

  0.106 inch

• Actuator Travel:

  2.2098 mm

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  15.3924 mm

• Body Height:

  10.8966 mm

• Body Length or Diameter:

  15.3924 mm

• Center Contact Plating:

  GOLD

• Contact (DC) Max Power Rating R Load:

  0.4VA@28VDC

• Contact Resistance:

  0.1 mΩ

• Dielectric Withstand Volts:

  1000VAC V

• Electrical Life:

  200000 Cycle(s)

• End Contact Plating:

  GOLD

• Illumination:

  LED

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  6

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPDT

• Switch Type:

  PUSHBUTTON SWITCH

• Terminal Finish:

  Gold (Au)

• Terminal Length:

  0.122 inch

• Termination Type:

  SOLDER
