ULP22EEP1QSSCL1REDNIL - E-Switch

ULP22EEP1QSSCL1REDNIL Details

• Manufacturer Part Number:

  ULP22EEP1QSSCL1REDNIL

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  E-Switch Inc

• YTEOL:

  0

• Actuator Length:

  0.335 inch

• Actuator Travel:

  2.2098 mm

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  15.3924 mm

• Body Height:

  10.8966 mm

• Body Length or Diameter:

  15.3924 mm

• Contact (AC) Max Rating R Load:

  0.2A@250VAC

• Contact Current(AC)-Max:

  0.2 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  0.5A@25VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  25 V

• Dielectric Withstand Volts:

  1000VAC V

• Electrical Life:

  200000 Cycle(s)

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  8

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Terminal Length:

  0.122 inch

• Termination Type:

  SOLDER
