ULQ2001A - STMicroelectronics

Description: Darlington Array 7 NPN 50V 0.5A PDIP16

Download ULQ2001A Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ULQ2001A - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
ULQ2001A - STMicroelectronics PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - DIP-08
click to zoom
3D Models
ULQ2001A - STMicroelectronics - 3D model - Dual-In-Line Packages - DIP-08
click to zoom

ULQ2001A Details

  • Manufacturer Part Number:

    ULQ2001A

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DIP

  • Package Description:

    DIP, DIP16,.3

  • Pin Count:

    16

  • Reach Compliance Code:

    Compliant

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    10 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    5.62

  • Built-in Protections:

    TRANSIENT

  • Driver Number of Bits:

    7

  • Input Characteristics:

    STANDARD

  • Interface IC Type:

    BUFFER OR INVERTER BASED PERIPHERAL DRIVER

  • JESD-30 Code:

    R-PDIP-T16

  • JESD-609 Code:

    e4

  • Length:

    19.18 mm

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Characteristics:

    OPEN-COLLECTOR

  • Output Current Flow Direction:

    SINK

  • Output Peak Current Limit-Nom:

    0.5 A

  • Output Polarity:

    INVERTED

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP16,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Seated Height-Max:

    5.33 mm

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Turn-off Time:

    1 µs

  • Turn-on Time:

    1 µs

  • Width:

    6.6 mm

ULQ2001A Frequently Asked Questions (FAQs)

  • STMicroelectronics provides a recommended PCB layout in the application note AN4566, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and minimize electromagnetic interference (EMI).
  • The selection of external components depends on the specific application and operating conditions. STMicroelectronics provides a component selection guide in the datasheet, and also recommends using their online simulation tool, STMicroelectronics' Power Designer, to optimize component selection and ensure stable operation.
  • The maximum ambient temperature range for the ULQ2001A is -40°C to +125°C. Operating the device outside this range can affect its performance, including reduced efficiency, increased power consumption, and potential damage to the device. It's essential to ensure proper thermal management and cooling to maintain optimal performance.
  • STMicroelectronics provides a troubleshooting guide in the application note AN4566, which covers common issues and their possible causes. Additionally, engineers can use oscilloscopes and other diagnostic tools to identify and resolve issues. It's also recommended to consult with STMicroelectronics' technical support team for further assistance.
  • Yes, the ULQ2001A is compatible with lead-free soldering processes. STMicroelectronics recommends following the JEDEC standard J-STD-020D for lead-free soldering, with a peak temperature of 260°C and a dwell time of 30 seconds.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ULQ2001A Overview

Use the download button to access the ULQ2001A schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ULQ20, or try a keyword search, such as Peripheral Drivers
