UMZ30NFMT106 - ROHM Semiconductor

UMZ30NFMT106 Details

• Manufacturer Part Number:

  UMZ30NFMT106

• Part Life Cycle Code:

  Active

• Package Description:

  SC-70, SOT-323, 3 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  7

• Additional Feature:

  HIGH RELIABILITY

• Breakdown Voltage-Max:

  30.69 V

• Breakdown Voltage-Min:

  29.19 V

• Breakdown Voltage-Nom:

  29.94 V

• Configuration:

  COMMON ANODE, 2 ELEMENTS, 2 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-G3

• Number of Elements:

  2

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, EMBOSSED, 7 INCH

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  0.2 W

• Reference Standard:

  IEC-61000-4-2

• Rep Pk Reverse Voltage-Max:

  27 V

• Reverse Current-Max:

  0.1 µA

• Reverse Test Voltage:

  23 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
