UPA3753GR-E2-AX - Renesas Electronics

UPA3753GR-E2-AX Details

• Manufacturer Part Number:

  UPA3753GR-E2-AX

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOP

• Package Description:

  SOP-8

• Pin Count:

  8

• Manufacturer Package Code:

  PRSP0008DD

• Reach Compliance Code:

  Compliant

• ECCN Code:

  5A002

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  5.4

• Avalanche Energy Rating (Eas):

  2.5 mJ

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  60 V

• Drain Current-Max (ID):

  5 A

• Drain-source On Resistance-Max:

  0.072 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  32 pF

• JESD-30 Code:

  R-PDSO-G8

• JESD-609 Code:

  e4

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  1.12 W

• Pulsed Drain Current-Max (IDM):

  20 A

• Surface Mount:

  YES

• Terminal Finish:

  NICKEL PALLADIUM GOLD

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
