UPC2905AHB-AZ - Renesas Electronics

UPC2905AHB-AZ Details

• Manufacturer Part Number:

  UPC2905AHB-AZ

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MP-3

• Package Description:

  LEAD FREE, SC-64, 3 PIN

• Pin Count:

  3

• Manufacturer Package Code:

  PRSS0004ZM

• ECCN Code:

  5A002

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  1 V

• Input Voltage-Max:

  16 V

• Input Voltage-Min:

  6 V

• JESD-30 Code:

  R-XSIP-T3

• JESD-609 Code:

  e6

• Length:

  6.5 mm

• Line Regulation-Max:

  0.05%

• Load Regulation-Max:

  0.05%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  3

• Output Voltage1-Max:

  5.25 V

• Output Voltage1-Min:

  4.75 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SIP

• Package Equivalence Code:

  SIP3,.04,90TB

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  7.5 mm

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.3 mm

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  2.3 mm
