UPD44164085AF5-E40-EQ2 - Renesas Electronics

UPD44164085AF5-E40-EQ2 Details

• Manufacturer Part Number:

  UPD44164085AF5-E40-EQ2

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  BGA

• Pin Count:

  165

• ECCN Code:

  3A991.b.2.a

• HTS Code:

  8542.32.00.41

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Access Time-Max:

  0.45 ns

• Clock Frequency-Max (fCLK):

  250 MHz

• I/O Type:

  SEPARATE

• JESD-30 Code:

  R-PBGA-B165

• Memory Density:

  16777216 bit

• Memory IC Type:

  STANDARD SRAM

• Memory Width:

  8

• Number of Terminals:

  165

• Number of Words:

  2097152 words

• Number of Words Code:

  2000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  2MX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA165,11X15,40

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY

• Parallel/Serial:

  PARALLEL

• Qualification Status:

  Not Qualified

• Standby Current-Max:

  0.28 A

• Standby Voltage-Min:

  1.7 V

• Supply Current-Max:

  0.45 mA

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM
