UPD8048D - Renesas Electronics

UPD8048D Details

• Manufacturer Part Number:

  UPD8048D

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP-40

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Bit Size:

  8

• CPU Family:

  8048

• JESD-30 Code:

  R-CDIP-T40

• JESD-609 Code:

  e0

• Number of Terminals:

  40

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DIP

• Package Equivalence Code:

  DIP40,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• RAM (bytes):

  64

• ROM (words):

  1024

• ROM Programmability:

  MROM

• Speed:

  6 MHz

• Supply Current-Max:

  135 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  MOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL
