USB-A3-C31-D-RA-CS1 Details

• Manufacturer Part Number:

  USB-A3-C31-D-RA-CS1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Adam Technologies Inc

• Board Mounting Option:

  LOCATING POSTS

• Body Breadth:

  0.625 inch

• Body Depth:

  0.681 inch

• Body Length:

  0.543 inch

• Connector Type:

  USB CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  MIXED

• Contact Resistance:

  40 mΩ

• Contact Style:

  USB A + USB C

• Dielectric Withstanding Voltage:

  100VAC V

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2+4

• Number of Ports:

  2

• Number of Rows Loaded:

  2+2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  MIXED

• PCB Contact Row Spacing:

  1.3 mm

• Plating Thickness:

  FLASH inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  5 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  STAINLESS STEEL

• Terminal Length:

  0.071 inch

• Terminal Pitch:

  1.6 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  33

• UL Flammability Code:

  94V-0
