USB-A3-S-RA-SMT - Adam Tech

USB-A3-S-RA-SMT Details

• Manufacturer Part Number:

  USB-A3-S-RA-SMT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Adam Technologies Inc

• Additional Feature:

  ROHS COMPLIANT

• Board Mounting Option:

  POLARIZATION POST

• Body Breadth:

  0.272 inch

• Body Depth:

  0.561 inch

• Body Length:

  0.634 inch

• Body/Shell Style:

  PLUG

• Connector Type:

  USB CONNECTOR

• Contact Finish Mating:

  AU ON NI

• Contact Gender:

  FEMALE

• Contact Material:

  BRASS

• Contact Resistance:

  30 mΩ

• Contact Style:

  USB SER A FLAT

• Dielectric Withstanding Voltage:

  500VAC V

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYETHYLENE

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  MOUNTING FLANGE

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Contact Pattern:

  RECTANGULAR

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1.5 A

• Reference Standard:

  CSA, UL

• Shell Finish:

  NICKEL

• Shell Material:

  STEEL

• Terminal Pitch:

  0.9906 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  9
