USB2242I-AEZG-XX - Microchip

USB2242I-AEZG-XX Details

• Manufacturer Part Number:

  USB2242I-AEZG-XX

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  QFN

• Package Description:

  6 X 6 MM, 0.50 MM PITCH, ROHS COMPLIANT, QFN-36

• Pin Count:

  36

• Country Of Origin:

  Thailand

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  5

• Host Data Transfer Rate-Max:

  35 MBps

• Host Interface Standard:

  USB

• JESD-30 Code:

  S-XQCC-N36

• Length:

  6 mm

• Number of Terminals:

  36

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC36,.25SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  140 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  6 mm

• uPs/uCs/Peripheral ICs Type:

  SECONDARY STORAGE CONTROLLER, FLASH MEMORY DRIVE
