USB50805E3/TR13 - Microsemi Corporation

USB50805E3/TR13 Details

• Manufacturer Part Number:

  USB50805E3/TR13

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  SOD

• Package Description:

  ROHS COMPLIANT, PLASTIC, SOP-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Breakdown Voltage-Min:

  6 V

• Configuration:

  SEPARATE, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-G8

• JESD-609 Code:

  e3

• Non-rep Peak Rev Power Dis-Max:

  500 W

• Number of Elements:

  2

• Number of Terminals:

  8

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity:

  UNIDIRECTIONAL

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
