USVD2-B10M-025-02 - Caddock

USVD2-B10M-025-02 Details

• Manufacturer Part Number:

  USVD2-B10M-025-02

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED-4

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  Caddock Electronics Inc

• YTEOL:

  7

• Additional Feature:

  ULTRA PRECISION

• Construction:

  Rectangular

• First Element Resistance:

  9900000 Ω

• JESD-609 Code:

  e3

• Lead Length:

  12.7 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Network Type:

  ISOLATED

• Number of Elements:

  1

• Number of Functions:

  2

• Number of Terminals:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  12.7 mm

• Package Length:

  38.1 mm

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  SIP

• Package Width:

  3.94 mm

• Resistor Type:

  ARRAY/NETWORK RESISTOR

• Second/Last Element Resistance:

  100000 Ω

• Surface Mount:

  NO

• Technology:

  METAL GLAZE/THICK FILM

• Temperature Coefficient:

  10 ppm/°C

• Terminal Finish:

  MATTE TIN

• Terminal Shape:

  WIRE

• Tolerance:

  0.1%

• Working Voltage:

  1400 V
