V10PWL63C-M3/I - Vishay

V10PWL63C-M3/I Details

• Manufacturer Part Number:

  V10PWL63C-M3/I

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DPAK-3/2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Factory Lead Time:

  5 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6.22

• Additional Feature:

  LOW POWER LOSS, FREE WHEELING DIODE

• Application:

  EFFICIENCY

• Case Connection:

  CATHODE

• Configuration:

  COMMON CATHODE, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.6 V

• JEDEC-95 Code:

  TO-252AE

• JESD-30 Code:

  R-PSSO-G2

• Non-rep Pk Forward Current-Max:

  80 A

• Number of Elements:

  2

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, PLASTIC, 13 INCH

• Rep Pk Reverse Voltage-Max:

  60 V

• Reverse Current-Max:

  80 µA

• Reverse Test Voltage:

  60 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE
