V110A24C400BL Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and thermal management for optimal performance?
  Vicor recommends a 4-layer PCB with a solid ground plane and a thermal pad connected to a heat sink or a thermal interface material. The datasheet provides a recommended PCB layout and thermal management guidelines.
• How do I ensure reliable start-up and shutdown of the V110A24C400BL?
  To ensure reliable start-up and shutdown, Vicor recommends a soft-start circuit and a controlled shutdown sequence. The application note AN-104 provides more details on start-up and shutdown considerations.
• What are the EMI and RFI considerations for the V110A24C400BL?
  The V110A24C400BL is designed to meet CISPR 22 Class B and FCC Part 15 Class B emissions standards. Vicor recommends following proper PCB layout and shielding techniques, as well as using EMI filters and common-mode chokes to minimize emissions.
• Can I use the V110A24C400BL in a high-reliability or military application?
  Yes, the V110A24C400BL is available in a variety of screening options, including JANS, ESCC, and MIL-PRF-38534. Vicor also offers a range of high-reliability and military-grade components that meet specific industry standards.
• What is the maximum operating temperature range for the V110A24C400BL?
  The V110A24C400BL has an operating temperature range of -40°C to +125°C, with derating required above 100°C. Vicor recommends following the thermal management guidelines to ensure reliable operation within the specified temperature range.
