Littelfuse recommends a PCB layout with a large copper area connected to the thermal tab to dissipate heat efficiently. A minimum of 1 oz copper thickness is recommended, and the copper area should be at least 1 inch x 1 inch in size.
To ensure reliable soldering, Littelfuse recommends using a soldering iron with a temperature range of 250°C to 260°C, and a solder with a melting point of 180°C to 190°C. The component should be soldered within 3 seconds to 5 seconds, and the solder joints should be inspected for proper wetting and filleting.
The V131HB34 has a maximum surge current rating of 100 A for 8.3 ms, as per the IEC 61000-4-5 standard. However, it's essential to consult the datasheet and application notes for specific surge current requirements and derating factors.
The V131HB34 is designed for low-frequency applications up to 400 Hz. While it may be possible to use it in high-frequency applications, Littelfuse recommends consulting their application engineers to determine the suitability of the device for specific high-frequency requirements.
Littelfuse recommends storing the V131HB34 in its original packaging, away from direct sunlight, moisture, and extreme temperatures. The devices should be handled with electrostatic discharge (ESD) precautions, such as using ESD-safe gloves, wrist straps, and work surfaces.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
V131HB34 Overview
Use the download button to access the V131HB34 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like V131H,
or try a keyword search, such as Non-linear Resistors
