V23040-A0001-B201 - TE Connectivity

V23040-A0001-B201 Details

• Manufacturer Part Number:

  V23040-A0001-B201

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  10 mm

• Body Height:

  8.5 mm

• Body Length or Diameter:

  20 mm

• Coil Current(DC)-Max:

  0.016 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  80 mW

• Coil Resistance:

  320 Ω

• Coil Voltage(DC)-Max:

  16.5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  60VA@125VAC

• Contact (AC) Max Rating R Load:

  2A@125VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Power Rating R Load:

  60W@150VDC

• Contact (DC) Max Rating R Load:

  2A@150VDC

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  150 V

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  Palladium Nickel

• End Contact Plating:

  Gold

• Input Switching Control Type:

  Random

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  7

• Operate Time:

  3 ms

• Operating Temperature-Max:

  85 °C

• Physical Dimension:

  20mm x 10mm x 8.5mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  CHANGE-OVER

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  1.6 ms

• Sealing:

  IP67

• Surface Mount:

  NO

• Terminal Length:

  0.003500127000254001 inch

• Termination Type:

  SOLDER
