V23072C1061A303 - TE Connectivity

V23072C1061A303 Details

• Manufacturer Part Number:

  V23072C1061A303

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  14.7 mm

• Body Height:

  19.2 mm

• Body Length or Diameter:

  16.9 mm

• Coil Operate Voltage(DC):

  6.9 V

• Coil Power:

  1100 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  130 Ω

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  5 A

• Contact (DC) Max Rating R Load:

  5A@12VDC

• Contact Voltage(DC)-Max:

  12 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  200000 Cycle(s)

• End Contact Material:

  Silver Nickel Oxide

• Input Switching Control Type:

  Random

• Number of Terminals:

  7

• Operate Time:

  3 ms

• Physical Dimension:

  16.9mm x 14.7mm x 19.2mm

• Relay Action:

  LATCHED

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  1.5 ms

• Terminal Length:

  0.002999745999491999 inch

• Termination Type:

  SOLDER
