V23079C1101B301 - TE Connectivity

V23079C1101B301 Details

• Manufacturer Part Number:

  V23079C1101B301

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Factory Lead Time:

  54 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.2

• Body Breadth:

  7.2 mm

• Body Height:

  9.8 mm

• Body Length or Diameter:

  14.5 mm

• Coil Current(DC)-Max:

  0.014 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  357 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  2A@250VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Rating R Load:

  2A@220VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  220 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1500 Vrms

• Dielectric Strength Between Open Contacts:

  1000 Vrms

• Electrical Life:

  200000 Cycle(s)

• End Contact Material:

  SILVER NICKEL

• Insertion Loss-Max:

  -0.27 dB

• Insulation Resistance:

  1000000000000 Ω

• Isolation-Max:

  -20.7 dB

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  8 ms

• Operating Frequency-Max:

  900 MHz

• Operating Frequency-Min:

  100 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  15mm X 7.5mm X 9.9mm

• Reference Standard:

  CSA; UL

• Relay Action:

  LATCHED

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  8 ms

• Sealing:

  IP67

• Surface Mount:

  NO

• Switching Time:

  16 ms

• Termination Type:

  SOLDER/QUICK CONNECT

• VSWR:

  1.4

• Weight:

  2.8 g
