V23092-A1024-A302 - TE Connectivity

V23092-A1024-A302 Details

• Manufacturer Part Number:

  V23092-A1024-A302

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Body Breadth:

  5 mm

• Body Height:

  15 mm

• Body Length or Diameter:

  28 mm

• Coil Current(DC)-Max:

  0.007 A

• Coil Operate Voltage(DC):

  16.8 V

• Coil Power:

  170 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  3390 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  6A@400VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact Voltage(AC)-Max:

  400 V

• Contact/Output Supply Type:

  AC

• Dielectric Strength Between Coil and Contacts:

  1000 Vrms

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  28mm x 5mm x 15mm

• Reference Standard:

  UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  7.5 ms

• Sealing:

  RT3

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  6 g
