V23100V4324C000 - TE Connectivity

V23100V4324C000 Details

• Manufacturer Part Number:

  V23100V4324C000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  7 mm

• Body Height:

  7.5 mm

• Body Length or Diameter:

  19.3 mm

• Coil Current(DC)-Max:

  0.012 A

• Coil Operate Voltage(DC):

  16.8 V

• Coil Power:

  34 mW

• Coil Release Voltage(DC):

  3.6 V

• Coil Resistance:

  2000 Ω

• Coil Voltage(AC)-Max:

  28 V

• Coil Voltage(DC)-Max:

  28 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  1.2 A

• Contact Current(DC)-Max:

  1.2 A

• Contact (DC) Max Rating R Load:

  0.4A@175VDC

• Contact Resistance:

  150 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1500 Vrms

• Dielectric Strength Between Open Contacts:

  200 Vrms

• Electrical Life:

  5000000 Cycle(s)

• End Contact Material:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  8

• Operate Time:

  1.1 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  19.3mm x 7.6mm x 7.5mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  SPDT

• Relay Type:

  DRY REED RELAY

• Release Time:

  1.6 ms

• Surface Mount:

  NO

• Terminal Length:

  0.003200406400812802 inch

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  1.8 g
