V23136-L0031-D642 - TE Connectivity

V23136-L0031-D642 Details

• Manufacturer Part Number:

  V23136-L0031-D642

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Factory Lead Time:

  10 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.26

• Body Breadth:

  27.8 mm

• Body Height:

  25.3 mm

• Body Length or Diameter:

  27.8 mm

• Coil Operate Voltage(DC):

  6 V

• Coil Power:

  1300 mW

• Coil Release Voltage(DC):

  6 V

• Coil Resistance:

  25 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  80 A

• Contact Current(DC)-Max:

  80 A

• Contact (DC) Max Rating R Load:

  80A@12VDC

• Contact Voltage(DC)-Max:

  12 V

• Contact/Output Supply Type:

  DC

• Dielectric Strength Between Coil and Contacts:

  500 Vrms

• Dielectric Strength Between Open Contacts:

  500 Vrms

• End Contact Material:

  SILVER ALLOY

• Input Switching Control Type:

  Random

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  4

• Operate Time:

  2 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  27.8mm x 27.8mm x 25.3mm

• Relay Action:

  LATCHED

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  1 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  35 g
