V300A15E500BL - VICOR

V300A15E500BL Details

• Manufacturer Part Number:

  V300A15E500BL

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Package Description:

  PACKAGE-9

• Pin Count:

  9

• ECCN Code:

  EAR99

• Factory Lead Time:

  22 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  5.48

• Additional Feature:

  REMOTE SHUTDOWN

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, TUV, CE

• Efficiency (Main Output):

  86%

• Input Voltage-Max:

  375 V

• Input Voltage-Min:

  180 V

• Input Voltage-Nom:

  300 V

• JESD-30 Code:

  R-XDFM-P9

• JESD-609 Code:

  e0

• Length:

  116.84 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -10 °C

• Output Current-Max:

  43.5 A

• Output Voltage-Max:

  16.5 V

• Output Voltage-Min:

  1.5 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  0.0884 Vrms

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Finish:

  Tin/Lead (Sn90Pb10) - with Nickel (Ni) barrier

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  500 W

• Trim/Adjustable Output:

  YES

• Width:

  55.88 mm
