VB024 - STMicroelectronics

VB024 Details

• Manufacturer Part Number:

  VB024

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZFM

• Package Description:

  ISOWATT-7

• Pin Count:

  7

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Built-in Protections:

  TRANSIENT; OVER CURRENT

• Input Characteristics:

  SCHMITT TRIGGER

• Interface IC Type:

  LATCH BASED PERIPHERAL DRIVER

• JESD-30 Code:

  R-PZFM-T7

• JESD-609 Code:

  e0

• Number of Functions:

  1

• Number of Terminals:

  7

• Output Characteristics:

  OPEN-COLLECTOR

• Output Current Flow Direction:

  SINK

• Output Peak Current Limit-Nom:

  8 A

• Output Polarity:

  INVERTED

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  15 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Supply Voltage1-Max:

  16 V

• Supply Voltage1-Min:

  5.5 V

• Supply Voltage1-Nom:

  12 V

• Surface Mount:

  NO

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG

• Turn-off Time:

  80 µs
