VESD05A5-06GHG3-08 - Vishay

VESD05A5-06GHG3-08 Details

• Manufacturer Part Number:

  VESD05A5-06GHG3-08

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  SOT-363, 6 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Date Of Intro:

  2019-07-04

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  0

• Additional Feature:

  BOX: 15000

• Breakdown Voltage-Max:

  7.65 V

• Breakdown Voltage-Min:

  6.85 V

• Breakdown Voltage-Nom:

  7.26 V

• Clamping Voltage-Max:

  11.5 V

• Configuration:

  COMMON ANODE, 5 ELEMENTS

• Diode Capacitance-Min:

  53 pF

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-G6

• Non-rep Peak Rev Power Dis-Max:

  100 W

• Number of Elements:

  5

• Number of Terminals:

  6

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, 7 INCH

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  AEC-Q101; IEC-61000-4-2, 4-5

• Rep Pk Reverse Voltage-Max:

  5 V

• Reverse Current-Max:

  0.1 µA

• Reverse Test Voltage:

  5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
