VHF25-12io7 - LITTELFUSE

VHF25-12io7 Details

• Manufacturer Part Number:

  VHF25-12IO7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.30.00.80

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7.02

• Case Connection:

  ISOLATED

• Configuration:

  BRIDGE, HALF-CONTROLLED, COMMON CATHODE WITH BUILT-IN DIODE

• DC Gate Trigger Current-Max:

  25 mA

• DC Gate Trigger Voltage-Max:

  1.5 V

• Desc. of Quick-Connects:

  0

• Desc. of Screw Terminals:

  0

• Holding Current-Max:

  50 mA

• JESD-30 Code:

  R-XUFM-X6

• JESD-609 Code:

  e4

• Leakage Current-Max:

  5 mA

• Non-Repetitive Pk On-state Cur:

  200 A

• Number of Elements:

  2

• Number of Terminals:

  6

• On-state Current-Max:

  16000 A

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• RMS On-state Current-Max:

  25.12 A

• Repetitive Peak Off-state Voltage:

  1200 V

• Repetitive Peak Reverse Voltage:

  1200 V

• Surface Mount:

  NO

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Trigger Device Type:

  SCR
