VNLD5090-E - STMicroelectronics

Description: Gate Drivers OMNIFET III fully protect lo-side drvr

Download VNLD5090-E Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
VNLD5090-E - STMicroelectronics PCB footprint - Small Outline Packages - Small Outline Packages - SO8_1
click to zoom
3D Models
VNLD5090-E - STMicroelectronics  - 3D model - Small Outline Packages - SO8_1
click to zoom

VNLD5090-E Details

  • Manufacturer Part Number:

    VNLD5090-E

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    SOP-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    0

  • Built-in Protections:

    TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL

  • Interface IC Type:

    BUFFER OR INVERTER BASED PERIPHERAL DRIVER

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    4.9 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    2

  • Number of Terminals:

    8

  • Output Current Flow Direction:

    SINK

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    4.5 V

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Palladium/Silver/Gold (Ni/Pd/Ag/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

VNLD5090-E Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the input and output tracks as short as possible and use a common mode choke to reduce EMI.
  • Use a heat sink with a thermal resistance of less than 10°C/W and ensure good airflow around the device. Also, reduce the output current to prevent overheating.
  • The maximum allowed voltage drop is 1.5V. Exceeding this may cause the device to malfunction or reduce its lifespan.
  • Yes, VNLD5090-E is suitable for battery-powered applications due to its low quiescent current (IQ) of 5mA. However, ensure proper power management to minimize power consumption.
  • Use a voltage supervisor or a reset IC to monitor the input voltage and reset the device if it falls outside the recommended operating range (7V to 18V).
