VPTF1-28 - VPT

VPTF1-28 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and thermal management for optimal performance?
  VPT recommends a 4-layer PCB with a dedicated power plane, and thermal vias under the device to ensure efficient heat dissipation. A minimum of 2 oz copper thickness is recommended for the power plane.
• How do I ensure reliable start-up and shutdown of the VPTF1-28?
  To ensure reliable start-up and shutdown, VPT recommends a soft-start circuit to limit inrush current, and a voltage supervisor to monitor the input voltage and prevent unwanted shutdowns.
• What are the EMI and RFI considerations for the VPTF1-28?
  VPT recommends using a shielded enclosure, and following good EMI design practices such as keeping sensitive components away from the DC-DC converter, using EMI filters, and minimizing loop areas.
• Can I use the VPTF1-28 in a high-reliability or high-temperature application?
  Yes, the VPTF1-28 is designed for high-reliability and high-temperature applications. It is qualified to MIL-PRF-38534 and has a maximum operating temperature of 125°C. However, derating may be required for extreme temperature conditions.
• How do I troubleshoot common issues with the VPTF1-28, such as output voltage deviations or shutdowns?
  VPT recommends using a oscilloscope to monitor the input and output voltages, and checking the enable and fault pins for any anomalies. A detailed troubleshooting guide is available in the VPT application note AN-104.
