VS-E5PH7506L-N3 - Vishay

VS-E5PH7506L-N3 Details

• Manufacturer Part Number:

  VS-E5PH7506L-N3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Italy

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Factory Lead Time:

  10 Weeks

• Date Of Intro:

  2020-10-18

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6

• Application:

  EFFICIENCY

• Breakdown Voltage-Min:

  600 V

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.7 V

• JEDEC-95 Code:

  TO-247AD

• JESD-30 Code:

  R-PSFM-T2

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  615 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  75 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Packing Method:

  TUBE

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  25 µA

• Reverse Recovery Time-Max:

  0.057 µs

• Reverse Test Voltage:

  600 V

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE
