VSC30-2812S/ES+ - VPT Inc

VSC30-2812S/ES+ Details

• Manufacturer Part Number:

  VSC30-2812S/ES+

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan, USA

• ECCN Code:

  EAR99

• Manufacturer:

  VPT Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  84%

• Input Voltage-Max:

  50 V

• Input Voltage-Min:

  15 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-PDMA-P10

• Length:

  47.88 mm

• Line Regulation-Max:

  0.1666%

• Load Regulation-Max:

  0.1666%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  2.5 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,10LEAD,1.6

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; SHORT CIRCUIT; UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.0176 Vrms

• Screening Level:

  MIL-STD-883

• Seated Height-Max:

  9.14 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Dose:

  30k Rad(Si) V

• Total Power Output-Max:

  30 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.01 s

• Width:

  33.66 mm
